Quick Specs (Mobile-Friendly)
| Category | Details |
| Type | Tiltable Downlight |
| Power Range | 8W – 30W |
| Beam Angle | 11° – 50° |
| CCT Options | 2700K–6500K (Tunable White) / 1800K–3000K (Dim-to-Warm) |
| IP Rating | IP44 / IP65 |
| Dimming | DALI / 0–10V / Phase |
| Mounting | Recessed (Round / Square options) |
| Adjustability | Tiltable |
Dimensions & Cutout
Ø72 × H105 mm
1. Cutout: 80 mm
2. Power: 8W / 12W / 15W
Ø103 × H140 mm
1. Cutout: 110 mm
2. Power: 15W / 20W / 25W / 30W
Finish Options
1. Trim: White / Black
2. Body: Black
3. Reflector: Nickel Black, Matt Black, Matt White, Shining Silver, Gold
Advanced Features
1. Zhaga-Compatible Light Engine – Easy upgrades & optical flexibility
2. Complete Optical System – Lenses + reflectors interchangeable
3. IP Module Swap – Convert IP44 to IP65 by hand
4. Edge-Free Design – Clean architectural finish
5. Optical Accessories – Honeycomb mesh, stretch filters, single/double polarization
What this really means for your project
You don’t need multiple SKUs for different applications.
One fixture adapts on-site—beam, color, protection level, even accessories.
That’s less inventory, faster installs, and more control over the final lighting scene.
